Off Road Forklift (4WD)

Category：

4T Rough Terrain Forklift（4WD）

We are located in Shandong Province, China, specializing in the manufacture of handling and loading equipment suitable for agriculture, construction and industrial industries. Diken's products, such as telehandler, rough terrain forklift, telescopic wheel loader, are widely used in farms

Consult Back

4T Rough Terrain Forklift

1.1	Model		DK40
1.2	Power Type		Diesel
1.3	Rated Capacity	kg	4000
1.4	Load Center Distance	mm	550
1.5	Drive Type		4WD

Dimension Parameter

2.1	Standard Lift Height	mm	3000
2.2	Fork Size(LWH)	mm	1370×120×50
2.3	Mast inclination angle (F/R)	Deg	12\12
2.4	Overall Length (without fork)		3370
2.5	（Overall Width）	mm	1900
2.6	Mast Height	mm	2370
2.8	Head Guard Height	mm	2525
2.10	Ground Clearance	mm	310
2.11	Minimum Turning Radius	mm	3800
2.12	Wheelbase	mm	1850
2.13	Front wheel tread	mm	1570
2.14	Rear wheel tread	mm	1400
2.15	Self Weight	kg	6000
2.16	Overall Height(2 Stage 3m Mast)	mm	2525
2.17	Overall Height(2 Stage 4m Mast)	mm	2920
2.18	Overall Height(2 Stage 5m Mast)	mm	3420
2.19	Overall Height(3 Stage 5m Mast)	mm	2635
2.20	Overall Height(3 Stage 6m Mast)	mm	2985

Performance Parameter

3.1	Maximum Travel Speed	Km\h	32
3.2	Lifting Speed	mm\s	430
3.3	Lowering Speed	mm\s	420
3.4	Maximum Gradeability	％	35

Tire

4.1	Front Tyre	16/70-20
4.2	Rear Tyre	10-16.5

Engine and Gearbox

5.1	Battery	V\Ah	24\120
5.2	Engine Manufacturer		YunNei
5.3	Engine Model		YN4EZ070-32
5.4	Rated Power/RPM	kw	60/2400
5.5	Fuel Tank Capacity	L	90
5.6	Gearbox Model		265
5.7	Transmission Type		Hydrodynamic
5.9	Optional engines	Cummins 4BTA3.9-C80 60KW

Technical parameters are subject to change without prior notice.
Please call us for details。

The Off Road Forklift (4WD): Unleashing Unparalleled Performance

The Off Road Forklift (4WD) is a revolutionary piece of machinery that stands out for its exceptional capabilities in diverse and challenging terrains. This forklift is specifically designed to overcome the obstacles that come with off-road conditions, offering reliable and efficient operation.

With its four-wheel drive system, the Off Road Forklift (4WD) provides enhanced traction and maneuverability. It can effortlessly navigate through mud, sand, gravel, and uneven surfaces, ensuring smooth and stable movement even in the most demanding environments. This makes it ideal for use in construction sites, mines, agricultural areas, and other outdoor settings where normal forklifts might struggle.

The build quality of this forklift is robust and durable. It is constructed using high-quality materials that can withstand the rigors of heavy-duty use and harsh weather conditions. The chassis is engineered to be sturdy and resistant to impacts, while the components are precision-built to ensure long-lasting performance.

The lifting capacity of the Off Road Forklift (4WD) is impressive, allowing it to handle substantial loads with ease. Whether it’s lifting pallets of materials, containers, or other heavy objects, it delivers reliable and consistent power. The hydraulic system is designed for smooth and precise lifting and lowering operations, ensuring safe handling of the loads.

The operator cabin of the Off Road Forklift (4WD) is designed for comfort and convenience. It provides a comfortable seating position, adjustable controls, and clear visibility of the working area. Advanced safety features such as seat belts, rollover protection, and braking systems are incorporated to safeguard the operator during operation.

In addition to its core functionality, the Off Road Forklift (4WD) offers flexibility in its applications. It can be equipped with various attachments and accessories to adapt to specific tasks and requirements. For example, it can be fitted with forks of different lengths and widths, or other specialized attachments for handling specific materials or performing specialized operations.

Maintenance of the Off Road Forklift (4WD) is relatively straightforward. Regular inspections, fluid checks, and proper servicing are essential to keep it in optimal condition. The parts and components are easily accessible, facilitating quick and efficient maintenance and repairs.

Overall, the Off Road Forklift (4WD) is a game-changer in the world of material handling. Its ability to operate effectively in off-road conditions, combined with its durability, lifting capacity, and user-friendly design, makes it a valuable asset for a wide range of industries. Whether it’s for construction, agriculture, or any other off-road application, this forklift is sure to meet the toughest challenges and deliver outstanding results. It is a true testament to engineering excellence and is set to revolutionize the way we handle materials in off-road environments.
